CM230

Sink on Drum Part Washer

Request a Quote

The CM230 is our best-selling solvent parts washer that fits efficiently into any part washing process. This sink on drum machine with integrated wash spigot and flow-through wash brush puts powerful solvent cleaning at your fingertips.

Function

This Efficient and compact parts cleaner offers rugged 16GA drawn steel construction at great value. Flexible rinse spigot and flow-through wash brush with independent flow control brings versatility to this workstation. Available accessories bring additional functionality and quality of life improvements to this efficient performer.

Features

  • 3 cu.ft. 31” x 23” x 7.25” work volume with additional large part work height clearance
  • 75 lbs. weight capacity
  • Extra deep drawn sink for part and spray containment
  • 30-gallon drum and capacity
  • 205 GPM @ 1 ft. rated pump with triple seal Viton shaft seal for long service life
  • 115 VAC, 1.1A electrical requirement
  • Flexible wash spigot with integrated ball-valve flow control
  • Flow-through wash brush with integrated push button flow control
  • Tough 16GA construction for the sink and lid to handle harsh work environments
  • Sink is fully epoxy powder coated
  • High-grade brand name components throughout
  • Simple lift-off sink with no tools required for easy drum access and service
Specifications

Overall Dimensions: 35.5” W x 26.5” D x 63” H (drum, open lid)

Shipping Dimensions: 36.5” L x 30.5” W x 15.5” H

Shipping Weight: 80 Lbs.
