Immersion parts washer for delicate parts cleaning
Industrial parts cleaning for automotive workshops

EM80

Agitating Lift Washer

Request a Quote

The EM80 is our medium aqueous agitating lift part washer built for heavy-duty tasks using agitation capable of cleaning deep into crevices and blind holes. The lift and tray are suitable for parts and batch cleaning up to 250 lbs.

Function

Submerged agitation paired with detergents and heat remove greases, sludge, dirt, and debris provide clean parts with minimal effort. Agitation tank washers are well suited for parts with difficult to reach crevices, blind holes, and internal volumes where external spray or manual scrubbing doesn’t reach.

Features

  • Heavy Duty 12GA 304 Stainless Steel Tank
  • 5 Sq.Ft., 41.5” x 17.5” Lift Platform
  • 250 Lbs. Weight Capacity
  • 80-Gallon Fluid Capacity
  • Low Friction Roller Wheels (No power robbing slides)
  • Modular 6kW Heating Available in 230V or 460V 1 PH
  • On/Off Heating with 130°F Thermostat Preset
  • Thermostat Over-Temp Protection
  • 0.75 HP Industrial Pump 20 GPM @ 28 PSI
  • Fire Safety Fusible Link for Lid and Lift
  • 80mm Cylinder 930 lbs. Peak Force @ 120 PSI
  • Flow Requirements: 3 CFM @ 120 PSI
Specifications

Overall Dimensions: 37.5” L x 51.7” W x 68.8” H

Shipping Dimensions: 43” L x 57” W x 56” H

Shipping Weight: 700 Lbs.
